Features & Benefits
• Significant energy savings thanks to exceptional thermal performance compliant with the passive house certification standard.
• Multi-chamber central seal ensures optimal waterproofing, preventing energy loss.
• Increased natural light thanks to the minimalist design
• Ease of use and high functionality
• High level of security thanks to multiple perimeter locking
• Modern design
• Simplified accessibility in compliance with regulations for people with special needs and children
• Wide range of types and solutions
• Greater static resistance and functionality even in extreme weather conditions
• Window type: Casement
• Thermal insulation: Yes
• External shape: Flat
Technical characteristics
• Frame depth: 89.5 mm
• Sash depth: 97 mm
• Minimum surface height: 102 mm
• Sash weight: up to 180 kg
• Glazing type: Triple
• Maximum glazing thickness: 48-80 mm
• Mechanism: Euro-groove, Euro-nut
• Sealing method: 3-level perimeter with EPDM gaskets
• Minimum threshold height: 20 mm
• Thermal insulation type: 54 polyamide mm, Kooltherm Q3, insulating foam
Performance
• Uf = 0.76 W/m²K
• Watertightness (EN 12208): Class 6A
• Air permeability (EN 12207): Class 3
• Wind load resistance (EN 12210): Class C4
• Burglar resistance: RC1/RC2/RC3
• Thermal transmittance Uw = 0.9 W/m²K
Types
1. Single-sash casement window
2. Double-sash casement window
3. Single-sash casement French door with low threshold
4. Double-sash casement French door with low threshold
5. Single-sash casement/tilt and turn window with fixed transom
6. Double-sash casement/tilt and turn window with fixed transom
7. Double-sash casement/tilt and turn window with opening transom
